Alloy Steel Forged Fittings
Stellanox Steel is a trusted manufacturer and supplier of premium Alloy Steel Forged Fittings, built to deliver high performance in high-pressure, high-temperature, and corrosive service environments. Our forged fittings are widely used in oil refineries, power plants, chemical processing units, and shipbuilding, offering leak-proof connections and long-lasting reliability.
With precise machining and heat treatment, Stellanox Steel’s forged fittings ensure superior strength, dimensional accuracy, and durability under dynamic and static loads.
What are Alloy Steel Forged Fittings?
Alloy Steel Forged Fittings are pipe connection components manufactured through hot forging and precision machining. They are used to connect pipes, valves, and equipment in systems that demand exceptional mechanical strength and corrosion resistance.
Made from heat-treatable alloy grades like A182 F5, F9, F11, F22, and F91, these fittings are engineered to handle high-pressure applications, thermal cycling, and aggressive media, making them ideal for industrial use in refineries, thermal power plants, and chemical industries.
Key Features of Alloy Steel Forged Fittings
- High Mechanical Strength: Withstands high internal pressures without deformation.
- Superior Resistance to Heat and Corrosion: Suitable for high-temperature, aggressive service.
- Excellent Impact and Fatigue Resistance: Ideal for dynamic loading and vibration-prone systems.
- Leak-Proof, Precision Fit: Manufactured to tight tolerances for secure, efficient assembly.
- Multiple Connection Types: Available in threaded (NPT/BSPT), socket weld, and custom connections.
- Tested and Certified: Compliant with global standards (ASME, ANSI, DIN, EN).
Specification Chart – Alloy Steel Forged Fittings
| Property | Details |
|---|---|
| Product | Alloy Steel Forged Fittings |
| Common Grades | ASTM A182 F1, F5, F9, F11, F22, F91 |
| Types Available | Elbow (45°, 90°), Tee, Coupling, Cross, Cap, Union, Bushing, Plug |
| Connection Types | Socket Weld (SW), Threaded (NPT/BSPT), Custom Threads |
| Sizes | ½" to 4" (DN15–DN100) |
| Class Ratings | 2000#, 3000#, 6000#, 9000# |
| Standards | ASME B16.11, MSS SP-83, BS 3799, DIN 2999 |
| Heat Treatment | Normalized, Quenched & Tempered, Annealed |
| Testing and Certification | Hydro, UT, MPI, PMI, IGC, EN 10204 3.1/3.2, NACE MR0175 |
Chemical Composition Chart – Alloy Steel Forged Fittings
| Element | Symbol | Composition (%) |
|---|---|---|
| Carbon | C | 0.05 – 0.15 |
| Chromium | Cr | 1.90 – 2.60 |
| Molybdenum | Mo | 0.87 – 1.13 |
| Manganese | Mn | 0.30 – 0.60 |
| Silicon | Si | 0.50 Max |
| Phosphorus | P | ≤ 0.030 |
| Sulfur | S | ≤ 0.030 |
| Iron | Fe | Balance |
Mechanical Properties Chart –Alloy Steel Forged Fittings
| Property | Value |
|---|---|
| Tensile Strength (MPa) | ≥ 415 |
| Yield Strength (MPa) | ≥ 205 |
| Elongation (%) | ≥ 20 |
| Hardness (HB) | ≤ 197 |
| Creep & Fatigue Resistance | Excellent |
Equivalent Grades Chart – Alloy Steel Forged Fittings
| Standard | Equivalent Grade |
|---|---|
| ASTM | A182 F5, F9, F11, F22, F91 |
| EN | 13CrMo4-5, 10CrMo9-10 |
| DIN | 1.7335, 1.7380 |
| JIS | SFVC2, SFVC3 |
Alloy Steel Forged Fittings Weight Chart (kg/m²)
| Fitting Type | Size (inches) | Approx. Weight (kg) | Description |
|---|---|---|---|
| Socket Weld Elbow | 1" | 0.34 | 90° elbow for socket weld pressure connections |
| Socket Weld Tee | 1" | 0.45 | Tee with socket weld ends for high-pressure use |
| Threaded Coupling | 1" | 0.38 | Full coupling with internal threads |
| Hex Plug | 1" | 0.15 | Threaded plug with hex head to seal pipe ends |
| Union | 1" | 0.60 | Three-piece union for detachable joint sealing |
Applications of Alloy Steel Forged Fittings in Various Industries
Benefits of Alloy Steel Forged Fittings
- Pressure and Heat Endurance: Withstands thermal cycling and mechanical loads.
- Reliable and Leak-Proof Connections: Prevents failures in critical systems.
- Superior Longevity: Reduced downtime and maintenance in harsh environments.
- High Weldability: Simplifies on-site fabrication and pipeline integration.
- Cost-Effective in Long-Term Use: Withstands corrosion and mechanical wear.
