Stainless Steel Coil
Stellanox Steel is a trusted manufacturer and supplier of high-quality Stainless Steel Coils, designed for superior performance across diverse industrial and commercial applications. Our coils are produced using premium raw materials and advanced processing techniques to ensure excellent mechanical properties, corrosion resistance, and consistent surface finishes.
With a comprehensive range of grades, sizes, and finishes, our stainless steel coils cater to industries such as construction, automotive, energy, food processing, and manufacturing worldwide.
What are Stainless Steel Coils?
Stainless Steel Coils are continuous, wound strips of stainless steel, offering versatility and adaptability for a wide range of applications. They are manufactured by hot-rolling or cold-rolling stainless steel slabs into thin strips and then coiling them for easy transport, storage, and further fabrication.
Coils are widely used as raw material for manufacturing sheets, strips, pipes, tubes, kitchenware, and industrial equipment. Thanks to their superior strength, resistance to corrosion, and easy formability, stainless steel coils play a critical role in modern manufacturing and infrastructure projects.
| Products |
|---|
|
Stainless Steel |
|
Carbon Steel |
|
Duplex Stainless Steel |
|
Super Duplex Stainless Steel |
|
Alloy Steel |
|
Titanium |
|
Hastelloy |
|
Inconel |
|
Monel |
|
Aluminium |
|
Copper |
|
Pure Nickel |
|
Flanges |
|
Forged Fittings |
|
Valves |
|
Fasteners |
Key Features of Stainless Steel Coils
- Excellent Corrosion Resistance: Withstands moisture, chemicals, and atmospheric exposure.
- Superior Strength and Durability: Ideal for mechanical and structural applications.
- Flexibility for Further Processing: Easily cut, stamped, drawn, or fabricated into various products.
- Wide Range of Finishes and Grades: Available in 2B, BA, No.4, No.8 (Mirror), and custom finishes.
- Consistent Surface Quality: Uniform thickness and appearance throughout the coil.
- Cost-Effective for Mass Production: Ideal for large-scale industrial manufacturing and fabrication.
Detailed Specification Chart
| Property | Specification |
|---|---|
|
Standard |
ASTM A240, A480, JIS G4305, EN 10088-2
|
|
Material Grades |
304, 304L, 316, 316L, 321, 347, 409, 410, 430 |
|
Thickness Range |
0.2 mm to 6.0 mm |
|
Width Range |
600 mm to 2000 mm |
|
Coil ID |
508 mm, 610 mm |
|
Surface Finishes |
2B, BA, No.4, No.8, Satin, Hairline |
|
Edge Condition |
Mill Edge, Slit Edge |
|
Coil Weight |
1 to 15 tons (as per requirement) |
|
Process Type |
Hot Rolled (HR) / Cold Rolled (CR) |
Chemical Composition Chart
| Element | Percentage (%) |
|---|---|
|
Carbon (C) |
≤ 0.08 |
|
Manganese (Mn)
|
≤ 2.00 |
|
Silicon (Si) |
≤ 0.75
|
|
Phosphorus (P) |
≤ 0.045 |
|
Sulfur (S) |
≤ 0.030 |
|
Chromium (Cr) |
18.00 – 20.00
|
|
Nickel (Ni) |
8.00 – 10.50 |
Mechanical Properties Chart
| Property | Value |
|---|---|
|
Tensile Strength (MPa) |
515 min
|
|
Yield Strength 0.2% (MPa)
|
205 min |
|
Elongation (%) |
40 min |
|
Hardness (HRB) |
70 – 90
|
|
Modulus of Elasticity (GPa)
|
193 |
Equivalent Grades Chart
| Standard | Equivalent Grade |
|---|---|
|
UNS |
S30400
|
|
EN |
X5CrNi18-10 |
|
WNR |
1.4301 |
|
JIS |
SUS 304 |
Stainless Steel Coil Weight Chart
| Thickness (mm) | Width (mm) | Length (m) | Weight (kg) |
|---|---|---|---|
|
0.3 |
1000 |
1000 |
2.4 |
|
0.5 |
1000 |
1000 |
4.0 |
|
1.0 |
1000 |
1000 |
8.0 |
|
2.0 |
1000 |
1000 |
16.0 |
|
3.0 |
1250 |
1000 |
30.0 |
|
5.0 |
1500 |
1000 |
60.0 |
Applications of Stainless Steel in Various Industries
Benefits of Stainless Steel Coils
- Versatile Raw Material: Can be easily converted into sheets, strips, pipes, and tubes.
- Corrosion Resistance in Harsh Environments: Ideal for both indoor and outdoor use.
- Superior Formability: Can be bent, stamped, and drawn into complex shapes.
- Aesthetic Value: Available in attractive polished, brushed, and mirror finishes.
- Durability and Longevity: Offers long-term value with minimal maintenance.
- Eco-Friendly Option: 100% recyclable with a low environmental footprint.
