Carbon Steel Wire
At Stellanox Steel, we manufacture and supply premium Carbon Steel Wire crafted for precision, strength, and versatility. Our carbon steel wires are produced under stringent quality controls, offering outstanding mechanical properties, excellent surface finishes, and superior performance across a wide range of industrial applications.
Available in multiple grades, tempers, diameters, and finishes, Stellanox Steel’s Carbon Steel Wire is ideal for construction, automotive, agricultural, fabrication, and general engineering industries.
What are Carbon Steel Wire?
Carbon Steel Wire is a long, thin product made from carbon steel rods drawn through dies to achieve the desired diameter and mechanical characteristics.
Depending on carbon content (low, medium, or high) and surface finish (bright, galvanized, black annealed), carbon steel wire serves a wide array of needs — from reinforcement in construction to springs, fasteners, fencing, and wire mesh manufacturing.
High carbon wire grades are typically used for applications requiring greater tensile strength, while low carbon wires offer superior ductility and weldability.
| Products |
|---|
|
Stainless Steel |
|
Carbon Steel |
|
Duplex Stainless Steel |
|
Super Duplex Stainless Steel |
|
Alloy Steel |
|
Titanium |
|
Hastelloy |
|
Inconel |
|
Monel |
|
Aluminium |
|
Copper |
|
Pure Nickel |
|
Flanges |
|
Forged Fittings |
|
Valves |
|
Fasteners |
Key Features of Carbon Steel Wire
- High Strength-to-Weight Ratio: Combines excellent tensile strength with lightweight construction.
- Good Ductility and Formability: Easily bent, twisted, or fabricated without cracking.
- Available in Multiple Tempers: Annealed, Hard Drawn, Spring Hard, Oil Tempered.
- Surface Options: Bright Finish, Black Annealed, Galvanized, Coated.
- Superior Weldability: Suitable for welding and forming processes.
- Wide Diameter Range: Fine wire to heavy-duty industrial wire.
Specification Chart – Carbon Steel Wire
| Property | Details |
|---|---|
|
Product |
Carbon Steel Wire |
|
Manufacturing Standards |
ASTM A510, ASTM A853, EN 10270-1, JIS G3506 |
|
Available Grades |
1008, 1010, 1045, 1060, 1070, 1080 |
|
Wire Forms |
Coil, Spool, Cut Length, Straightened & Cut Wire |
|
Diameter Range |
0.15 mm to 16.0 mm |
|
Surface Finish Options |
Bright, Black Annealed, Hot-Dip Galvanized, Electro-Galvanized |
|
Temper/Hardness Options |
Soft Annealed, Half Hard, Full Hard, Spring Hard |
|
Packaging Options |
Coils (5 kg to 500 kg), Spools, Bundles, Drums |
|
Heat Treatment |
Annealed, Oil Tempered, Normalized (for spring wires) |
Chemical Composition Chart – Carbon Steel Wire (Example: SAE 1008)
| Element | Symbol | Composition (%) |
|---|---|---|
|
Carbon |
C |
0.08 max |
|
Manganese |
Mn |
0.30 – 0.50 |
|
Phosphorus |
P |
≤ 0.04 |
|
Sulfur |
S |
≤ 0.05 |
|
Iron |
Fe |
Balance |
Mechanical Properties Chart – Carbon Steel Wire (Example: General Soft Annealed Wire)
| Property | Value (Typical) |
|---|---|
|
Tensile Strength (MPa) |
350 – 700 (varies by temper) |
|
Yield Strength (MPa) |
250 – 500 |
|
Elongation (%) |
10% – 25% |
|
Hardness (Rockwell) |
55 – 85 HRB |
|
Modulus of Elasticity (GPa) |
190 – 210 |
Equivalent Grades Chart – Carbon Steel Wire
| Standard | Equivalent Grade |
|---|---|
|
ASTM |
A510, A853 |
|
EN |
EN 10270-1 (Patented, drawn wires) |
|
JIS |
G3506 SWM-B, SWRH 72A, 82B |
|
SAE |
1008, 1010, 1045, 1060, 1070, 1080 |
Carbon Steel Wire Weight Chart
| Diameter (mm) | Weight per 1000 m (kg) | Weight per 100 m (kg) | Weight per Meter (kg) |
|---|---|---|---|
|
0.5 |
0.15
|
0.015 |
0.0015 |
|
1.0 |
0.62 |
0.062 |
0.0062 |
|
1.5 |
1.39
|
0.139 |
0.0139 |
|
2.0 |
2.47
|
0.247 |
0.0247 |
|
3.0 |
5.55
|
0.555 |
0.0555 |
|
5.0 |
15.42
|
1.542 |
0.1542 |
Applications of Carbon Steel Wire
Benefits of Carbon Steel Wire
- Wide Range of Grades and Strengths: From soft annealed to spring hard applications.
- Excellent Ductility and Toughness: Suitable for forming and bending operations.
- High Tensile Strength (for spring wires): Perfect for load-bearing and dynamic components.
- Various Coatings Available: For rust resistance and specific environmental needs.
- Cost-Efficient: Affordable material for mass production of fabricated products.
- Eco-Friendly Material: Fully recyclable and supports sustainable development.
