Stainless Steel Wire
At Stellanox Steel, we manufacture and supply premium-grade Stainless Steel Wire known for its exceptional strength, flexibility, and corrosion resistance. Our stainless steel wires are produced using state-of-the-art technologies and rigorous quality controls to meet the demands of industries like automotive, construction, medical, aerospace, food processing, and marine applications.
Available in a range of grades, diameters, tempers, and surface finishes, Stellanox Steel’s stainless steel wire products deliver dependable performance in the most challenging environments.
What are Stainless Steel Wire?
Stainless Steel Wire is a drawn metal product composed of stainless steel alloys, available in various forms such as round, flat, shaped, and fine wires. It exhibits outstanding mechanical properties, including tensile strength, durability, and resistance to corrosion, heat, and chemical exposure.
Stainless steel wire is a highly versatile material used in construction (reinforcements), manufacturing (springs and fasteners), medical devices (surgical wires), and consumer products (wire mesh, cables). Its high strength-to-weight ratio, hygienic surface, and formability make it indispensable in modern industries.
| Products |
|---|
|
Stainless Steel |
|
Carbon Steel |
|
Duplex Stainless Steel |
|
Super Duplex Stainless Steel |
|
Alloy Steel |
|
Titanium |
|
Hastelloy |
|
Inconel |
|
Monel |
|
Aluminium |
|
Copper |
|
Pure Nickel |
|
Flanges |
|
Forged Fittings |
|
Valves |
|
Fasteners |
Key Features of Stainless Steel Wire
- Excellent Corrosion Resistance: Withstands moisture, acids, alkalis, and industrial atmospheres.
- High Tensile and Yield Strength: Reliable under heavy mechanical stresses.
- Flexibility and Ductility: Easily drawn, twisted, coiled, or formed without cracking.
- Thermal and Electrical Resistance: Suitable for high-temperature and electrical applications.
- Hygienic and Easy to Sterilize: Perfect for medical, food-grade, and clean-room applications.
- Available in Various Forms: Round, flat, spring wire, welding wire, mesh wire, and more.
Detailed Specification Chart
| Property | Specification |
|---|---|
|
Standards |
ASTM A313, ASTM A580, JIS G4314, EN 10270-3 |
|
Material Grades |
304, 304L, 316, 316L, 321, 347, 410, 430 |
|
Diameter Range |
0.05 mm to 12.00 mm |
|
Wire Forms |
Coil, Spool, Straight Cut, Mesh |
|
Wire Types |
Soft Annealed, Spring Hard, Quarter Hard, Half Hard, Full Hard |
|
Surface Finishes |
Bright, Matte, Electro-polished, Coated |
|
Coil Weight |
5 kg to 500 kg (based on diameter) |
|
Tensile Strength Range |
500 MPa to 2000 MPa (depending on grade and temper) |
Chemical Composition Chart
| Element | Percentage (%) |
|---|---|
|
Carbon (C) |
≤ 0.08 |
|
Manganese (Mn) |
≤ 2.00 |
|
Silicon (Si) |
≤ 1.00 |
|
Phosphorus (P) |
≤ 0.045 |
|
Sulfur (S) |
≤ 0.030 |
|
Chromium (Cr) |
16.00 – 18.00 |
|
Nickel (Ni) |
10.00 – 14.00 |
|
Molybdenum (Mo) |
2.00 – 3.00 |
Mechanical Properties Chart
| Property | Value |
|---|---|
|
Tensile Strength (MPa) |
520 – 760
|
|
Yield Strength 0.2% (MPa)
|
205 min |
|
Elongation (%) |
40 min |
|
Hardness (HRB) |
70 – 90 (depending on temper) |
|
Modulus of Elasticity (GPa) |
193 |
Equivalent Grades Chart
| Standard | Equivalent Grade |
|---|---|
|
UNS |
S31600 |
|
EN |
X5CrNiMo17-12-2 |
|
WNR |
1.4401 |
|
JIS |
SUS 316 |
Weight Chart
| Diameter (mm) | Weight per 1000 m (kg) | Weight per 100 m (kg) | Weight per Meter (kg) |
|---|---|---|---|
|
0.5 |
0.16 |
0.016 |
0.0016 |
|
1.0 |
0.62 |
0.062 |
0.0062 |
|
1.5 |
1.40 |
0.140 |
0.0140 |
|
2.0 |
2.49 |
0.249 |
0.0249 |
|
3.0 |
5.60 |
0.560 |
0.0560
|
|
5.0 |
15.60 |
1.560 |
0.1560 |
|
1.0 |
50 |
0.39 |
3.90 / 39.00 |
|
1.2 |
75 |
0.71 |
7.10 / 71.00 |
|
1.5 |
100 |
1.18 |
11.80 / 118.00 |
|
2.0 |
100 |
1.57 |
15.70 / 157.00 |
|
2.5 |
125 |
2.45 |
24.50 / 245.00 |
|
3.0 |
150 |
3.53 |
35.30 / 353.00 |
|
4.0 |
150 |
4.71 |
47.10 / 471.00 |
|
5.0 |
200 |
7.85 |
7.85 |
Applications of Stainless Steel in Various Industries
Benefits of Stainless Steel Wire
- Exceptional Strength: Handles high-stress, tension, and impact applications reliably.
- Long-Term Corrosion Resistance: Performs well in harsh environments and exposure conditions.
- Superior Hygiene Standards: Non-porous surface ideal for sterile and food-safe environments.
- Wide Range of Forms and Finishes: Tailored to suit specific industry needs and aesthetic requirements.
- Cost-Efficient Longevity: Reduces replacement and maintenance costs over time.
- Eco-Friendly Manufacturing: Stainless steel wire is fully recyclable without loss of properties.
