Carbon Steel
As a trusted carbon steel manufacturer and supplier, Stellanox Steel delivers high-quality carbon steel products to industries worldwide. Whether you require carbon steel plate, sheet, pipe, tubes, coil, strip, or round bars, we offer a comprehensive range of carbon steel types and grades to meet your project specifications. Discover why Stellanox Steel is the preferred partner for carbon steel solutions across diverse applications.
What is Carbon Steel?
Carbon Steel is an iron-carbon alloy with up to 2.1% carbon content and trace amounts of elements like manganese, silicon, and sulfur. It is one of the most widely used engineering materials due to its excellent strength, workability, and cost-effectiveness.
Carbon steel is broadly categorized into:
- Low Carbon Steel (Mild Steel) – ≤ 0.3% carbon, used for general fabrication, structural applications
- Medium Carbon Steel – 0.3–0.6% carbon, used in automotive parts and forging
- High Carbon Steel – > 0.6% carbon, used for tools, springs, and wear-resistant components
| Products |
|---|
|
Stainless Steel |
|
Carbon Steel |
|
Duplex Stainless Steel |
|
Super Duplex Stainless Steel |
|
Alloy Steel |
|
Titanium |
|
Hastelloy |
|
Inconel |
|
Monel |
|
Aluminium |
|
Copper |
|
Pure Nickel |
|
Flanges |
|
Forged Fittings |
|
Valves |
|
Fasteners |
Key Features of Carbon Steel
- High Strength & Durability – Ideal for structural frameworks and load-bearing systems
- Cost-Effective Material – Affordable for bulk industrial use
- Excellent Machinability & Weldability – Supports cutting, welding, bending, and forming
- Wide Range of Grades & Forms – Plates, sheets, tubes, pipes, bars, coils, strips, and wires
- Adaptable to Surface Coating – Can be galvanized, painted, or oiled for corrosion resistance
- High Temperature Compatibility – Used in boilers, pressure vessels, and heat exchangers
Carbon Steel Products
Specification Chart – Carbon Steel (General)
| Property | Details |
|---|---|
|
Product Forms
|
Sheets, Plates, Coils, Pipes, Tubes, Bars, Wire
|
|
Grades |
ASTM A36, A106, A516, A283, EN 10025, IS 2062 |
|
Manufacturing Standards |
ASTM, ASME, EN, DIN, IS, JIS |
|
Surface Finish Options |
Black, Galvanized, Bright, Oiled, Painted |
|
Available Thickness |
0.2 mm – 100 mm |
|
Available Width/OD |
Up to 2000 mm (Sheets), 355 mm (Pipes/Tubes) |
|
End Finish (Pipes) |
Plain End (PE), Beveled End (BE), Threaded End |
|
Testing & Certification |
EN 10204 3.1, Hydrotest, NDT, Chemical/Mech. Test |
Chemical Composition Chart – Carbon Steel (Typical for A36)
| Element | Composition (%) |
|---|---|
|
Carbon (C) |
≤ 0.26 |
|
Manganese (Mn) |
0.60 – 0.90 |
|
Phosphorus (P) |
≤ 0.04 |
|
Sulfur (S) |
≤ 0.05 |
|
Silicon (Si) |
≤ 0.40 |
|
Iron (Fe) |
Balance |
Mechanical Properties Chart – Carbon Steel (Typical for A36)
| Property | Value |
|---|---|
|
Tensile Strength (MPa) |
400 – 550 MPa
|
|
Yield Strength (MPa) |
≥ 250 MPa |
|
Elongation (%) |
≥ 20% |
|
Hardness (HRB) |
≤ 200 HB |
|
Modulus of Elasticity |
~200 GPa |
Equivalent Grades Chart – Carbon Steel
| Standard | Equivalent Grade |
|---|---|
|
ASTM |
A36, A106, A283, A516 |
|
EN |
S235JR, S275JR, S355JR |
|
IS |
IS 2062 E250/E350 |
|
JIS |
SS400, SPHC |
|
DIN |
St 37-2, RSt 37-2 |
Carbon Steel Weight Chart (kg/m²)
| Thickness (mm) | IS 2062 / A36 / S275JR | A516 Gr.70 | SAE 1018 |
|---|---|---|---|
|
1 |
7.85 |
7.85 |
7.85 |
|
2 |
15.70 |
15.70 |
15.74 |
|
3 |
23.55
|
23.55 |
23.61 |
|
4 |
31.40
|
31.40 |
31.48 |
|
5 |
39.25 |
39.25 |
39.35 |
|
6 |
47.10
|
47.10 |
47.22 |
|
8 |
62.80
|
62.80
|
62.96 |
|
10 |
78.50
|
78.50 |
78.70
|
|
12 |
94.20
|
94.20 |
94.44 |
|
16 |
125.60 |
125.60 |
125.92 |
|
20 |
157.00
|
157.00 |
157.40 |
|
25 |
196.25 |
196.25 |
196.75 |
|
30 |
235.50
|
235.50 |
236.10 |
|
40 |
314.00
|
314.00 |
314.80 |
|
50 |
392.50
|
392.50 |
393.50 |
Applications of Carbon Steel in Various Industries
Stellanox Steel’s Carbon Steel products are valued for their strength, machinability, and cost-effectiveness across multiple sectors:
Oil And Gas Industry
Marine Industry
Building And Structural Steel
Power and Energy
Aerospace
Defence
Benefits of Carbon Steel
- High Strength: Excellent tensile and yield strength makes it ideal for load-bearing and structural applications.
- Cost-Effective: More affordable than many alloy steels, offering a strong performance-to-price ratio.
- Versatile Grades: Available in low, medium, and high carbon forms to suit diverse engineering needs.
- Excellent Weldability & Machinability: Easily welded and machined, making it adaptable for fabrication and manufacturing.
- Durability: Withstands high impact and heavy stress without deforming or cracking.
- Recyclable: Can be reused and recycled without losing its mechanical properties, supporting sustainability goals.
- Wide Industrial Use: Trusted across construction, automotive, oil & gas, and heavy equipment sectors
Frequently Asked Questions
Explore our FAQs for insights on materials, customization, and delivery.
What are the main types and grades of carbon steel?
Carbon steel types include low carbon (mild), medium carbon, and high carbon steel, each with specific grades like A36, A516, and 1095, offering different balances of strength, ductility, and hardness.
What is the typical composition and density of carbon steel?
Carbon steel composition mainly includes iron and carbon, with small amounts of manganese, silicon, sulfur, and phosphorus. The average carbon steel density is about 7.85 g/cm³.
What are the key benefits and properties of carbon steel?
Carbon steel benefits include high strength, versatility, affordability, and ease of fabrication. Key properties are its mechanical strength, weldability, and adaptability across a wide temperature range.
What are the common uses of carbon steel products?
Carbon steel is widely used for structural beams, plates, pipes, tubes, coils, strips, and round bars in construction, automotive, energy, oil and gas, and manufacturing industries due to its reliability and performance.
