Stainless Steel Tube
At Stellanox Steel, we offer a wide range of Stainless Steel Tubes engineered to meet the highest industry standards for quality, strength, and corrosion resistance. Designed for demanding structural, mechanical, and aesthetic applications, our stainless steel tubes are available in various grades, dimensions, and finishes to suit your project requirements.
From architecture and automotive to process piping and instrumentation, Stellanox Steel’s stainless steel tubes deliver superior performance, precision, and long-term durability across diverse industries.
What are Stainless Steel Tubes?
Stainless Steel Tubes are hollow cylindrical products made from corrosion-resistant stainless steel alloys, crafted through seamless or welded processes. Tubes differ from pipes primarily by their emphasis on precise outer diameter (OD) measurements and wall thickness rather than fluid transport.
They are extensively used in structural, mechanical, and decorative applications where strength, aesthetic appeal, and reliability are paramount. With exceptional resistance to oxidation, chemicals, and high temperatures, stainless steel tubes are vital for industries that demand uncompromising quality and appearance.
| Products |
|---|
|
Stainless Steel |
|
Carbon Steel |
|
Duplex Stainless Steel |
|
Super Duplex Stainless Steel |
|
Alloy Steel |
|
Titanium |
|
Hastelloy |
|
Inconel |
|
Monel |
|
Aluminium |
|
Copper |
|
Pure Nickel |
|
Flanges |
|
Forged Fittings |
|
Valves |
|
Fasteners |
Key Features of Stainless Steel Tubes
- Precise Dimensional Accuracy: Critical for mechanical and structural applications.
- Superior Surface Finishes: Ideal for architectural, medical, and instrumentation applications.
- High Corrosion Resistance: Withstands exposure to chemicals, moisture, and atmospheric conditions.
- Strength and Durability: Excellent tensile and yield strength for structural stability.
- Fabrication Friendly: Easily bent, machined, welded, or formed without cracking.
- Available in Multiple Types: Seamless, welded, square, rectangular, round configurations.
Detailed Specification Chart
| Property | Specification |
|---|---|
|
Standard |
ASTM A213, ASTM A269, ASTM A554, ASTM A312
|
|
Material Grades |
304, 304L, 316, 316L, 321, 347, 409, 410 |
|
Tube Types |
Seamless, Welded, ERW, Bright Annealed |
|
Size Range (OD) |
6 mm to 219.1 mm |
|
Wall Thickness
|
0.5 mm to 12.7 mm |
|
Shape |
Round, Square, Rectangular |
|
Length |
6 meters standard (custom lengths on request) |
|
Surface Finishes |
2B, BA, Mirror, Satin, Hairline, Brushed |
|
End Finish |
Plain End, Bevelled End |
Chemical Composition Chart
| Element | Percentage (%) |
|---|---|
|
Carbon (C) |
≤ 0.08 |
|
Manganese (Mn)
|
≤ 2.00 |
|
Silicon (Si) |
≤ 0.75
|
|
Phosphorus (P) |
≤ 0.045 |
|
Sulfur (S) |
≤ 0.030 |
|
Chromium (Cr) |
18.00 – 20.00
|
|
Nickel (Ni) |
8.00 – 10.50 |
|
Iron (Fe) |
Balance |
Mechanical Properties Chart
| Property | Value |
|---|---|
|
Tensile Strength (MPa) |
515 min
|
|
Yield Strength 0.2% (MPa)
|
205 min |
|
Elongation (%) |
40 min |
|
Hardness (HRB) |
70 – 90
|
|
Modulus of Elasticity (GPa)
|
193 |
Equivalent Grades Chart
| Standard | Equivalent Grade |
|---|---|
|
UNS |
S30400
|
|
EN |
X5CrNi18-10 |
|
WNR |
1.4301 |
|
JIS |
SUS 304 |
Stainless Steel Tube Weight Chart
| OD (mm) | Wall Thickness (mm) | Weight per Meter (kg) | Weight per 6-Meter Length (kg) |
|---|---|---|---|
|
12.7 |
1.2 |
0.29 |
1.74 |
|
19.05 |
1.5 |
0.54 |
3.24 |
|
25.4 |
2.0 |
1.00 |
6.00 |
|
38.1 |
2.5 |
1.81 |
10.86 |
|
50.8 |
3.0 |
2.92 |
17.52 |
|
76.2 |
3.5 |
5.18
|
31.08 |
Applications of Stainless Steel in Various Industries
Benefits of Stainless Steel Tubes
- Precision Engineering: Tight tolerances make tubes perfect for high-precision installations.
- Corrosion and Oxidation Resistance: Excellent durability even in chemically aggressive or marine environments.
- Superior Aesthetic Appeal: Sleek, polished finishes are ideal for decorative and architectural uses.
- Versatile Fabrication: Easy to weld, cut, and bend into complex shapes.
- Long Service Life: Minimal maintenance with decades of reliable performance.
- Eco-Friendly: 100% recyclable material, supporting sustainable practices.
