Stainless Steel Bar
At Stellanox Steel, we manufacture and supply premium-grade Stainless Steel Bars designed for strength, versatility, and corrosion resistance. Available in a variety of shapes, including round, square, hexagonal, and flat, our stainless steel bars meet international standards for mechanical properties and quality.
Engineered for critical load-bearing applications and precision engineering components, Stellanox Steel’s stainless steel bars are trusted across industries like construction, automotive, aerospace, marine, energy, and manufacturing.
What are Stainless Steel Bars?
Stainless Steel Bars are solid, long metal products made from corrosion-resistant stainless steel alloys. They are produced through hot-rolling, cold-rolling, or forging processes and are available in multiple shapes and sizes to serve diverse structural and mechanical applications.
Due to their superior combination of mechanical strength, durability, machinability, and resistance to harsh environments, stainless steel bars are vital for everything from industrial equipment manufacturing to architectural structures and consumer goods.
| Products |
|---|
|
Stainless Steel |
|
Carbon Steel |
|
Duplex Stainless Steel |
|
Super Duplex Stainless Steel |
|
Alloy Steel |
|
Titanium |
|
Hastelloy |
|
Inconel |
|
Monel |
|
Aluminium |
|
Copper |
|
Pure Nickel |
|
Flanges |
|
Forged Fittings |
|
Valves |
|
Fasteners |
Key Features of Stainless Steel Bars
- High Strength and Durability: Excellent mechanical properties, ideal for structural and engineering use.
- Superior Corrosion Resistance: Resists rust, chemical attack, and extreme environments.
- Wide Range of Shapes and Sizes: Round, square, hex, flat, and custom profiles available.
- Ease of Fabrication: Suitable for machining, welding, forging, and forming operations.
- Temperature and Pressure Resistant: Performs reliably in high and low temperature conditions.
- Long Service Life: Minimal degradation over decades of use even in challenging conditions.
Detailed Specification Chart
| Property | Specification |
|---|---|
|
Standards |
ASTM A276, ASTM A479, ASTM A484
|
|
Material Grades |
304, 304L, 316, 316L, 321, 347, 410, 416, 431 |
|
Shape Options |
Round, Square, Hexagonal, Flat Bars |
|
Diameter (Round Bars) |
3 mm to 600 mm |
|
Size Range (Flat Bars) |
Thickness 3 mm to 150 mm, Width 10 mm to 500 mm |
|
Size Range (Square/Hex Bars) |
6 mm to 100 mm across flats
|
|
Length |
3 meters, 6 meters, or custom lengths |
|
Surface Finish |
Black, Bright, Peeled, Polished, Rough Turned |
Chemical Composition Chart
| Element | Percentage (%) |
|---|---|
|
Carbon (C) |
≤ 0.08 |
|
Manganese (Mn) |
≤ 2.00 |
|
Silicon (Si) |
≤ 0.75
|
|
Phosphorus (P) |
≤ 0.045 |
|
Sulfur (S) |
≤ 0.030 |
|
Chromium (Cr) |
18.00 – 20.00
|
|
Nickel (Ni) |
8.00 – 10.50
|
|
Iron (Fe) |
Balance |
Mechanical Properties Chart
| Property | Value |
|---|---|
|
Tensile Strength (MPa) |
515 min
|
|
Yield Strength 0.2% (MPa)
|
205 min |
|
Elongation (%) |
40 min |
|
Hardness (HRB) |
70 – 90 |
|
Modulus of Elasticity (GPa) |
193 |
Equivalent Grades Chart
| Standard | Equivalent Grade |
|---|---|
|
UNS |
S30400 |
|
EN |
X5CrNi18-10
|
|
WNR |
1.4301
|
|
JIS |
SUS 304
|
Stainless Steel Bar Weight Chart (Round)
| Diameter (mm) | Weight per Meter (kg) | Weight per 3-Meter (kg) | Weight per 6-Meter (kg) |
|---|---|---|---|
|
10 |
0.62 |
1.86 |
3.72 |
|
12 |
0.90 |
2.70 |
5.40 |
|
16 |
1.59 |
4.77 |
9.54 |
|
20 |
2.49 |
7.47 |
14.94 |
|
25 |
3.89 |
11.67 |
23.34 |
|
30 |
5.60 |
16.80
|
33.60 |
|
40 |
9.95 |
29.85 |
29.85 |
|
50 |
15.55 |
46.65 |
93.30 |
Applications of Stainless Steel in Various Industries
Stellanox Steel’s Stainless Steel products are trusted across sectors for their durability, corrosion resistance, and aesthetic appeal
Benefits of Stainless Steel Bars
- Exceptional Mechanical Strength: Withstands heavy loads and stresses without deformation.
- Long-Term Corrosion Protection: Durable against water, chemicals, and outdoor conditions.
- Superior Fabrication Compatibility: Easy to cut, weld, machine, and forge.
- Wide Availability in Shapes and Sizes: Adaptable to a multitude of project needs.
- Low Maintenance Costs: Resistant to wear and corrosion, reducing replacement cycles.
- Environmentally Sustainable: Fully recyclable, supporting green building initiatives.
