Aluminium
Stellanox Steel is a top supplier and stockist of premium aluminium products with outstanding corrosion resistance, better thermal conductivity, and lightweight construction applications. Aluminium is perfect for the automotive, aerospace, construction, marine, and packaging industries because of its high strength-to-weight ratio, recyclability, and non-magnetic nature.
Sheets, plates, tubes, bars, pipes, rods, coils, and forgings are just a few of the many grades and product forms of aluminium that we provide; all are produced in accordance with international quality standards.
What is Aluminium?
Aluminium is a lightweight, silvery-white metal that is renowned for being extremely ductile, non-toxic, and non-corrosive. Because of its easy workability, thermal/electrical conductivity, and formability, aluminum, the second most used metal in the world after iron—is essential to the engineering, transportation, building, and packaging sectors.
| Products |
|---|
|
Stainless Steel |
|
Carbon Steel |
|
Duplex Stainless Steel |
|
Super Duplex Stainless Steel |
|
Alloy Steel |
|
Titanium |
|
Hastelloy |
|
Inconel |
|
Monel |
|
Aluminium |
|
Copper |
|
Pure Nickel |
|
Flanges |
|
Forged Fittings |
|
Valves |
|
Fasteners |
Aluminium Products
- Aluminium Sheet
- Aluminium Plate
- Aluminium Round Bar
- Aluminium Pipes
- Aluminium Tubes
- Aluminium Pipe Fittings
Key Features
- Lightweight – One-third the density of steel
- Corrosion Resistant – Especially when anodized
- High Strength-to-Weight Ratio
- Non-Magnetic, Non-Toxic, Fully Recyclable
- Excellent Thermal & Electrical Conductivity
- Easy to Cut, Form, Machine, Weld, and Finish
Specification
| Property | Details |
|---|---|
| Product Forms | Sheet, Plate, Coil, Pipe, Tube, Bar, Rod, Wire, Forging |
| Grades Available | 1050, 1100, 2024, 5052, 5083, 6061, 6063, 7075 |
| Manufacturing Standards | ASTM B209, B211, B221, B241, AMS, EN 573, ISO 6361 |
| Density | 2.70 g/cm³ |
| Melting Point | ~660°C (1220°F) |
| Conductivity | ~60% of Copper (electrical), Very High (thermal) |
| Surface Finishes | Mill Finish, Brushed, Polished, Anodized, Powder Coated |
| Certification | EN 10204 3.1/3.2, ISO, ASTM, RoHS, REACH |
Chemical Composition
| Element | Composition (%) |
|---|---|
| Aluminium (Al) | Balance |
| Magnesium (Mg) | 0.8 – 1.2 |
| Silicon (Si) | 0.4 – 0.8 |
| Iron (Fe) | ≤ 0.7 |
| Copper (Cu) | 0.15 – 0.40 |
| Chromium (Cr) | 0.04 – 0.35 |
| Zinc (Zn) | ≤ 0.25 |
Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength | ≥ 290 MPa |
| Yield Strength | ≥ 240 MPa |
| Elongation | ≥ 10% |
| Hardness | ~95 HB |
| Modulus of Elasticity | 69 GPa |
Equivalent Grades
| Standard | Equivalent Grades |
|---|---|
| ASTM | 1050, 2024, 5052, 6061, 7075 |
| EN | AW-1050A, AW-2024, AW-6061 |
| UNS | A91050, A92024, A96061 |
| ISO | Al99.5, AlCu4Mg1, AlMgSi1 |
Weight
| Grade | Common Name | Unit (Form/Size) | Approx. Weight |
|---|---|---|---|
| AA 6061 | Aluminium 6061 | Sheet 3 mm (kg/m²) | 8.13 kg |
| AA 6082 | Aluminium 6082 | Round Bar Ø40 mm (kg/m) | 3.39 kg |
| ASTM B209 | Plate (Aluminium) | Plate 6 mm (kg/m²) | 16.26 kg |
| ASTM B241 | Seamless Pipe | Pipe OD 50.8 mm, WT 3 mm (kg/m) | 1.12 kg |
| ASTM B241 | Welded Pipe | Pipe OD 76.2 mm, WT 3.5 mm (kg/m) | 2.27 kg |
| ASTM B361 | Forged Fittings | Elbow 2" (avg. wt) | 0.37 kg |
Applications
- Aerospace & Aviation: Fuselages, wings, hydraulic systems, landing gear parts
- Automotive & Rail: Body panels, frames, heat exchangers, fuel systems
- Construction: Windows, curtain walls, structural framing, roofing
- Marine & Shipbuilding: Hulls, decks, hatches, anti-corrosive barriers
- Electrical: Busbars, power lines, heat sinks
- Packaging: Beverage cans, foils, food-grade containers
Benefits
- Lightweight Yet Strong – Reduces Transport & Structural Load
- Highly Corrosion Resistant, Especially in Coastal Environments
- Versatile for Fabrication – Cut, Bend, Weld, or Extrude
- Excellent Heat & Electrical Conductor
- Environmentally Friendly – Fully Recyclable with Low Energy Footprint
- Aesthetically Appealing for Modern Architecture & Design
