Aluminium Sheet
Stellanox Steel supplies high-quality Aluminium Sheets engineered for a wide range of lightweight, corrosion-resistant, and high-strength applications. Manufactured using advanced hot or cold rolling processes, our sheets are available in multiple grades including 1050, 1100, 2024, 5052, 5083, 6061, and 7075, tailored for automotive, aerospace, marine, construction, and packaging industries.
Available in mill finish, anodized, or coated forms, Aluminium sheets are known for their formability, conductivity, and superior performance in both indoor and outdoor conditions.
What are Aluminium Sheets?
Aluminium Sheets are flat-rolled metal products widely used due to their low weight, non-toxic nature, and high corrosion resistance. They are available in various alloys and temper conditions, making them suitable for both structural and decorative applications.
Common applications include aircraft skins, truck panels, facades, enclosure covers, electronic casings, and heat exchangers.
| Products |
|---|
|
Stainless Steel |
|
Carbon Steel |
|
Duplex Stainless Steel |
|
Super Duplex Stainless Steel |
|
Alloy Steel |
|
Titanium |
|
Hastelloy |
|
Inconel |
|
Monel |
|
Aluminium |
|
Copper |
|
Pure Nickel |
|
Flanges |
|
Forged Fittings |
|
Valves |
|
Fasteners |
Key Features
Lightweight – Ideal for transport, aerospace, and structural design
High Corrosion Resistance – Performs in moisture and marine environments
Excellent Workability – Easy to cut, form, and weld
Available in Various Alloys, Tempers, and Finishes
Non-Magnetic, Recyclable, and Aesthetically Appealing
Complies with ASTM, ASME, EN, and ISO Standards
Grades
- 1050 / 1100 Aluminium Sheet
- 3003 / 5052 Aluminium Sheet
- 6061 / 6063 Aluminium Sheet
- 2024 / 7075 Aluminium Sheet
Specification
| Property | Details |
|---|---|
| Product | Aluminium Sheet |
| Grades Available | 1050, 1100, 2024, 3003, 5052, 5083, 6061, 6063, 7075 |
| Manufacturing Standards | ASTM B209, EN 485-1/2, ISO 6361, AMS |
| Thickness Range | 0.5 mm to 6 mm |
| Width Range | 1000 mm to 2000 mm |
| Length Range | Up to 6000 mm (custom sizes on request) |
| Surface Finishes | Mill Finish, Brushed, Anodized, Powder Coated, PVDF Coated |
| Tempers | H14, H24, H32, O, T6, T651 |
| Certification | EN 10204 3.1/3.2, RoHS, REACH, ISO, ASTM Compliant |
Chemical Composition
| Element | Composition (%) |
|---|---|
| Aluminium (Al) | Balance |
| Magnesium (Mg) | 2.2 – 2.8 |
| Chromium (Cr) | 0.15 – 0.35 |
| Iron (Fe) | ≤ 0.40 |
| Silicon (Si) | ≤ 0.25 |
| Copper (Cu) | ≤ 0.10 |
| Zinc (Zn) | ≤ 0.10 |
Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength | ≥ 230 MPa |
| Yield Strength | ≥ 193 MPa |
| Elongation | ≥ 10% |
| Hardness | ~60 HB |
| Density | 2.68 g/cm³ |
Equivalent Grades
| Standard | Equivalent Grade |
|---|---|
| ASTM | 5052, 6061 |
| EN | AW-5052, AW-6061 |
| UNS | A95052, A96061 |
| ISO | AlMg2.5, AlMgSi1 |
Weight
| Thickness (mm) | Weight per m² (kg) | Weight per 2 m² (kg) | Weight per ft² (kg) |
|---|---|---|---|
| 0.5 | 1.36 | 2.72 | 0.13 |
| 1.0 | 2.71 | 5.42 | 0.25 |
| 1.5 | 4.07 | 8.14 | 0.38 |
| 2.0 | 5.42 | 10.84 | 0.50 |
| 2.5 | 6.78 | 13.56 | 0.63 |
| 3.0 | 8.13 | 16.26 | 0.76 |
| 4.0 | 10.84 | 21.68 | 1.01 |
| 5.0 | 13.55 | 27.10 | 1.26 |
| 6.0 | 16.26 | 32.52 | 1.51 |
Applications
Aerospace: Aircraft skins, wing panels, interior panels
Automotive: Body panels, fuel tanks, dashboards, cladding
Marine Industry: Hull skins, floors, bulkheads
Construction: Roofing, siding, curtain walls, ventilation ducts
Electrical: Cable shields, battery enclosures, conductors
Packaging: Cans, containers, foil-based lids
Benefits
Corrosion Resistant in Harsh Indoor & Outdoor Environments
Lightweight Material that Reduces Design Load
High Reflectivity and Surface Finish Options
Thermally and Electrically Conductive
Long Life Span with Minimal Maintenance
Sustainable – 100% Recyclable without Performance Loss
