Copper Plate
Stellanox Steel supplies premium-quality Copper Plates that offer exceptional thermal and electrical conductivity, corrosion resistance, and dimensional stability. Available in grades like C11000 (ETP Copper), C12200 (DHP Copper), and C17200 (Beryllium Copper), our copper plates are used in electrical systems, fabrication, industrial tooling, marine equipment, and architectural projects.
We provide copper plates in a range of thicknesses, finishes, and tempers, with custom cutting and international certifications as per client specifications.
What are Copper Plates?
Copper Plates are flat, rectangular sheets of copper that are thicker than standard copper sheets, typically used for machined components, busbars, high-performance electrical conductors, and decorative structures. Due to copper’s excellent thermal stability, formability, and corrosion resistance, these plates are ideal for engineering and electrical applications requiring consistent performance and longevity.
| Products |
|---|
|
Stainless Steel |
|
Carbon Steel |
|
Duplex Stainless Steel |
|
Super Duplex Stainless Steel |
|
Alloy Steel |
|
Titanium |
|
Hastelloy |
|
Inconel |
|
Monel |
|
Aluminium |
|
Copper |
|
Pure Nickel |
|
Flanges |
|
Forged Fittings |
|
Valves |
|
Fasteners |
Key Features
- Excellent Thermal and Electrical Conductivity
- Corrosion Resistant in Marine, Industrial, and Urban Conditions
- High Formability and Weldability
- Non-Magnetic, Antibacterial, and Aesthetic
- Available in Various Thicknesses and Tempers
- Conforms to ASTM, EN, BIS, and ISO Standards
Grades
- C10100 / C10200 Copper Plates
- C11000 / C12200 Copper Plates
- C17200 Beryllium Copper Plate
Specification
| Property | Details |
|---|---|
| Product | Copper Plate |
| Grades Available | C11000 (ETP), C12200 (DHP), C17200 (Beryllium), C10100 (Oxygen-Free) |
| Thickness Range | 6 mm to 100 mm |
| Width Range | Up to 2000 mm |
| Length Range | Up to 6000 mm (custom cut on request) |
| Tempers Available | O (Annealed), H02 (Half-Hard), H04 (Full Hard), H08 (Spring) |
| Finishes | Mill Finish, Polished, Brushed, Tinned, Bright |
| Standards | ASTM B152, B187, EN 1652, BIS 191, ISO 1634 |
| Certification | EN 10204 3.1/3.2, ISO, ASTM, RoHS, REACH |
Chemical Composition
| Element | Composition (%) |
|---|---|
| Copper (Cu) | ≥ 99.90 |
| Oxygen (O) | ≤ 0.04 |
| Others | ≤ 0.10 |
Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength | 210 MPa |
| Yield Strength | 70 MPa |
| Elongation | ≥ 30% |
| Hardness | 50 – 60 HRB |
| Conductivity | ~100% IACS |
Equivalent Grades
| Standard | Equivalent Grade |
|---|---|
| ASTM | B152 |
| EN | CW004A |
| ISO | Cu-ETP |
| BIS (India) | Cu-ETP, Cu-DLP |
Weight
| Thickness (mm) | Weight per m² (kg) | Weight per 2 m² (kg) | Weight per ft² (kg) |
|---|---|---|---|
| 6 | 53.64 | 107.28 | 4.98 |
| 8 | 71.52 | 143.04 | 6.63 |
| 10 | 89.40 | 178.80 | 8.29 |
| 12 | 107.28 | 214.56 | 9.94 |
| 16 | 143.04 | 286.08 | 13.25 |
| 20 | 178.80 | 357.60 | 16.57 |
| 25 | 223.50 | 447.00 | 20.70 |
| 30 | 268.20 | 536.40 | 24.84 |
| 40 | 357.60 | 715.20 | 33.12 |
| 50 | 447.00 | 894.00 | 41.40 |
Applications
- Electrical Engineering: Grounding plates, busbars, switchgear panels
- Industrial Tooling: Molds, electrodes, heat sinks, pressure pads
- Marine & Shipbuilding: Hull linings, anti-biofouling sheets
- Architecture & Interior Design: Wall panels, door trims, counters
- Transport & Aerospace: Transformer bases, thermal management components
- Oil & Gas: Cathodic protection panels, flare tip components
Benefits
- High Conductivity for Optimal Heat & Electricity Flow
- Corrosion Resistant in Saline, Industrial, and Acidic Environments
- Low Maintenance and Long Service Life
- Antimicrobial and Biostatic Properties
- Formable, Weldable, and Machinable
- Globally Certified for Critical Applications
Frequently Asked Questions
Explore our FAQs for insights on materials, customization, and delivery.
What’s the difference between copper plate and copper sheet?
Copper plates are thicker (typically >6 mm) and used for load-bearing and high-conductivity applications, while sheets are thinner and used for forming or decorative purposes.
Which grade of copper plate is best for electrical systems?
C11000 (ETP Copper) is ideal for electrical applications due to its 100% IACS conductivity.
Can copper plates be machined or welded?
Yes. Copper plates can be machined using carbide tools and welded using gas or TIG welding methods.
Are copper plates suitable for marine use?
Yes. Copper’s natural resistance to seawater and biofouling makes it an excellent material for marine systems.
