Titanium
At Stellanox Steel, we offer a full range of Titanium products that deliver unmatched strength-to-weight ratio, superior corrosion resistance, and outstanding biocompatibility. Ideal for critical industries such as aerospace, marine, chemical processing, medical, and defense, our titanium products combine lightweight durability with long-term performance in the most aggressive environments.
We supply titanium in various grades and forms — including sheets, plates, bars, pipes, tubes, wires, and fasteners — tailored to your specifications and project needs.
What is Titanium?
Titanium is a lustrous, corrosion-resistant metal renowned for its high strength, low density, and exceptional resistance to corrosion by seawater, aqua regia, and chlorine. Despite being as strong as steel, titanium is 45% lighter, making it an ideal material for aerospace, deep-sea, biomedical, and chemical applications.
Titanium is available in both commercially pure (CP) and alloyed grades, including the most common ones like Grade 2, Grade 5 (Ti-6Al-4V), Grade 7, and Grade 23 (Ti-6Al-4V ELI).
| Products |
|---|
|
Stainless Steel |
|
Carbon Steel |
|
Duplex Stainless Steel |
|
Super Duplex Stainless Steel |
|
Alloy Steel |
|
Titanium |
|
Hastelloy |
|
Inconel |
|
Monel |
|
Aluminium |
|
Copper |
|
Pure Nickel |
|
Flanges |
|
Forged Fittings |
|
Valves |
|
Fasteners |
Titanium Products
- Titanium Pipe Fittings
- Titanium Tube
- Titanium Plate
- Titanium Rod
Key Features
Exceptional Strength-to-Weight Ratio: Stronger than steel, but significantly lighter.
Unmatched Corrosion Resistance: Resistant to seawater, acids, and chlorides.
Biocompatible & Non-Toxic: Used in surgical implants and medical devices.
High Melting Point & Thermal Stability: Ideal for aerospace and heat-critical applications.
Excellent Fatigue and Crack Resistance: Long service life under cyclic loading.
Non-Magnetic & Low Thermal Expansion: Suitable for precision components and electronics.
Specification
| Property | Details |
|---|---|
| Grades Available | Grade 1, Grade 2, Grade 5 (Ti-6Al-4V), Grade 7, Grade 9, Grade 23 |
| Standards | ASTM B265, B348, B381, B337, B861, ASME SB265, SB348, MIL-T-9046 |
| Product Forms | Sheets, Plates, Bars, Rods, Tubes, Pipes, Wires, Forgings, Fittings |
| Density | ~4.51 g/cm³ (45% lighter than steel) |
| Melting Point | ~1668°C |
| Tensile Strength (Grade 5) | ~950 MPa (Quenched & Aged) |
| Modulus of Elasticity | 105 GPa |
| Heat Treatment Options | Annealed, Solution Treated & Aged |
| Applications | Aerospace, Marine, Chemical Processing, Medical, Energy |
Chemical Composition
| Element | Composition (%) |
|---|---|
| Titanium (Ti) | ≥ 99.5 (Grade 1), ≥ 99.2 (Grade 2 & 7), Balance (Grade 5 & 23) |
| Aluminium (Al) | 6.0 (Grade 5 & 23) |
| Vanadium (V) | 4.0 (Grade 5 & 23) |
| Iron (Fe) | ≤ 0.20 (Grade 1), ≤ 0.30 (Grade 2), ≤ 0.25 (Grade 5 & 7), ≤ 0.13 (Grade 23) |
| Oxygen (O) | ≤ 0.18 (Grade 1), ≤ 0.25 (Grade 2 & 7), ≤ 0.20 (Grade 5), ≤ 0.13 (Grade 23) |
| Palladium (Pd) | Present only in Grade 7 (exact % not specified) |
Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength (MPa) | 240 – 965 |
| Yield Strength (MPa) | 170 – 880 |
| Elongation (%) | ≥ 10 to ≥ 24 |
| Hardness | ~70 – 80 HB or ~34 – 36 HRC |
Equivalent Grades
| Standard | Equivalent Grade |
|---|---|
| ASTM / ASME | Grade 1, Grade 2, Grade 5, Grade 7, Grade 23 |
| UNS | R50250, R50400, R56400, R52400, R56401 |
| DIN | 3.7025, 3.7035, 3.7165, 3.7235, 3.7164 |
| ISO | 99.8 Ti, 99.7 Ti, Ti-6Al-4V, Ti-0.2Pd, Ti-6Al-4V ELI |
Weight
| Grade | Common Name | Unit (Form/Size) | Approx. Weight |
|---|---|---|---|
| Grade 1 | Commercially Pure (Soft) | Sheet 1 mm (kg/m²) | 4.51 kg |
| Grade 2 | Commercially Pure (Standard) | Round Bar Ø25 mm (kg/m) | 2.82 kg |
| Grade 5 | Ti-6Al-4V (Aerospace Alloy) | Sheet 5 mm (kg/m²) | 22.50 kg |
| Grade 7 | Ti-0.2Pd (Corrosion Resistant) | Sheet 2 mm (kg/m²) | 9.00 kg |
| Grade 23 | Ti-6Al-4V ELI (Medical Grade) | Round Bar Ø20 mm (kg/m) | 2.19 kg |
Applications
Aerospace: Jet engines, airframes, fasteners, landing gear
Marine: Seawater pipelines, heat exchangers, ship propellers
Medical: Orthopedic implants, dental implants, surgical instruments
Chemical Processing: Reactors, condensers, pressure vessels, piping
Power Generation: Heat exchangers, turbine blades, nuclear waste containers
Automotive & Sports Equipment: Racing components, exhausts, bicycles
Benefits
Unmatched Durability in Harsh Environments
Weight Savings Without Strength Compromise
Non-Toxic and Bio-Inert for Human Use
Non-Magnetic – Ideal for Electronics and MRI Compatibility
Corrosion-Proof in Seawater and Chloride Exposure
Long Lifecycle with Minimal Maintenance
